Multi-detector UPLC / UHPLC provides faster and more detailed analysis of polymer molecular weight, size and structure
Add multi-detection to your Waters ACQUITY APC™ or UHPLC system for faster and more detailed polymer analysis.
Do you have polydisperse polymers or oligomers and wish you were better able to resolve this distribution by size or molecular weight? A clearer understanding of the molecular weight distribution might be the difference between a working or a failing polymer. Or, would you like to do GPC/SEC measurements in half the time and using half the solvent (or less)? Saving time and solvent means higher productivity, greener chemistry, lower operating costs, and a quicker turnaround from plant production to lab analysis.
Ultra high performance liquid chromatography (UHPLC) and ultra performance liquid chromatography (UPLC) such as the Waters ACQUITY® APC™ are an advancement on traditional gel permeation chromatography (GPC) separations. Using advanced hybrid particles, which are smaller than in analytical GPC columns, ACQUITY APC columns offer improved resolutions, faster separation, reduced solvent use, and utilize low-dispersion (band broadening) hardware. A follow-on benefit is that the tall narrow peaks achieved using the ACQUITY APC help to improve sensitivity and reduce detection limits.
UPLC, or UHPLC (Ultra High Performance Liquid Chromatography) and HPLC are both liquid chromatography techniques to separate the components of a compound or mixture. The table below highlights some of the differences between these two separation techniques.
SEC-HPLC | SEC-U(H)PLC | |
Typical Column dimensions | 7.8 x 300 mm | 4.6 x 150 mm |
Particle size | 3 - 10 µm | < 3 µm |
Typical Run time per injection | 45 minutes | 10 minutes |
Solvent usage per injection | 45 mL | 10 mL |
Pump pressure | 4 MPa | 70 MPa |
Sample usage
(µg loading varies depending on sample and system set-up) | 300 µg | 20 µg |
Peak resolution | Good | Best |
Mobile phase change over | Normal | Fast |
Adding multiple advanced detectors, including light scattering and viscometry to UPLC setups offers superior information about polymers and oligomers, including absolute molecular weight, size, and structure, when compared with conventional single-detector measurements. Previously these two techniques have been incompatible due to band-broadening and dispersion effects that take place as narrow UPLC peaks pass through multiple detector cells. However, the latest enhancements to Malvern Panalytical's OMNISEC REVEAL detector platform now bring these two class leading technologies together. Combining the information-rich data from advanced multi-detection with the speed and resolution afforded by UPLC it is now possible to get the best of both worlds - faster and more detailed polymer analysis.
![]() 凝胶渗透色谱仪OMNISEC系统多检测器GPC/SEC系统 |
|
---|---|
更多细节 | |
技术类型 | |
凝胶渗透色谱法 | |
尺寸排阻色谱 (SEC) | |
静态光散射法 | |
测量类型 | |
分子结构 | |
分子尺寸 | |
分子量 | |
最小样品质量 (BSA) | 100ng |
最小样品质量(聚苯乙烯) | 100ng |
分子量范围 | 200Da - 10MDa |
